Description
The Kenwood Model KR-9600 stereo receiver is a product that has been perfected through many years of developmental efforts by an engineering team that takes great pride in its long tradition of quality high fidelity component design.

This new receiver extends the concept of component high fidelity to a level of performance never before associated with a single, integrated receiver.

From its dual power supplies to its FET differential amplifier phono input to its unique tape facilities and absolute state-of-the-art tuner design, this is a receiver which makes no compromise with separate components.

Specifications
Tuning range: FM, MW

Power output: 160 watts per channel into 8Ω (stereo)

Frequency response: 20Hz to 40kHz

Total harmonic distortion: 0.08%

Damping factor: 55

Input sensitivity: 1.5mV (mic), 2.5mV (MM), 150mV (DIN), 150mV (line)

Signal to noise ratio: 65dB (mic), 76dB (MM), 95dB (DIN), 95dB (line)

Output: 150mV (line), 30mV (DIN), 1V (Pre out)

Speaker load impedance: 4Ω to 16Ω

Dimensions: 580 x 169 x 420mm

Weight: 24kg
